TEB207-12 OGSI EC80-000157-12 Electronic Module Assembly

TEB207-12 OGSI EC80-000157-12 is a semiconductor equipment IO electronic module assembly from TEL Tokyo Electronics, used for signal interaction in Clean Track lithography cleaning machines.
Characteristics
1. Integrate multiple isolated I/O channels to collect stable signals from cavity sensors
2. Onboard communication interface, supporting SECS protocol, convenient for docking with device upper computer
3. The board has been equipped with specialized cleanroom protection to adapt to the working conditions inside the machine
4. The channel status indicator lights are complete, and on-site troubleshooting of signal faults is simple
5. Integrated assembly of the whole machine, directly plug and replace without dismantling scattered parts

parameter
1. Powered by 24V DC, the overall power consumption of the machine is not high
2. Digital and analog signal channels are integrated on the same board
3. Supports 10/100M Ethernet and RS485 communication
4. Working temperature -10 ℃~60 ℃, suitable for machine control cabinet
5. Original board card, specially adapted for TEL Lithium cleaning platform
Application
1. TEL Clean Track Lithography Cleaning Machine Signal Control
2. IO signal acquisition for semiconductor wafer process equipment
3. Interlock signal transmission of lithography track machine
4. Replacement of spare parts for old TEL cleaning equipment boards
5. Maintenance of process equipment in wafer manufacturing production lines
TEB207-12 is a core IO assembly for TEL cleaning track machines, and this spare part is often used for production line shutdown maintenance.
