IS200TTURH1CCC S1DF00Z Turbine Terminal Board

IS200TTURH1CCC S1DF00Z is a Mark VI/VIe turbine control system TTUR turbine terminal board, used as a signal transfer terminal between on-site sensors, actuators, and main control.
Product Features
1. Integrate multiple terminals and onboard relays to gather on-site signals such as speed, vibration, and pressure, and issue protection and control commands
2. Support TMR triple redundant architecture, cooperate with TRPG trip board and VTUR board to ensure reliable protection circuit of the unit
3. Built in signal isolation circuit to resist strong electromagnetic interference from power plants and reduce the risk of signal false triggering
4. Onboard hardware channel self-test, capable of identifying wire breakage and short circuit faults, uploading alarm information for easy fault location
5. Installation of cabinet backplane slots, clear wiring layout of terminal blocks, and on-site spare parts replacement to shorten downtime for maintenance

Product Specifications
1. Model: IS200TTURH1CCC S1DF00Z
2. Product Type: Turbine Terminal Block TTUR
3. Adaptation system: GE Speedtronic Mark VI/Mark VIe
4. Power supply: 24VDC
5. Interface: Terminal block+multiple sets of D-type connectors
Application Areas
1. Signal terminal of gas turbine unit control cabinet
2. Steam turbine protection and monitoring signal circuit
3. Replacement of Mark VIe control system maintenance spare parts for the power station
4. Turbine control system renovation project for generator set
5. Automated monitoring system for cogeneration units
The IS200TTURH1CCC S1DF00Z turbine terminal board is an important signal spare part for the turbine control system in the maintenance of the signal terminal circuit of the power plant turbine unit.
