IS200TSVCH1ADC S1CX01H Controller Module

IS200TSVCH1ADC S1CX01H is a Mark VI/VIe turbine control system TSVC servo terminal board, responsible for electro-hydraulic servo valve drive and valve position feedback acquisition.
Product Features
1. Dual channel servo current output, collecting multiple LVDT valve position feedback signals to achieve closed-loop regulation of fuel valve and guide vane
2. Channel electrical isolation design, blocking strong electrical interference on site and protecting the main control unit from impact
3. Support single/dual/triple redundant architecture, onboard hardware self diagnosis, real-time monitoring of channel disconnection and faults
4. Integrated relay voting circuit, capable of outputting interlocking alarm signals, in conjunction with unit protection logic
5. Backboard slot installation, compatible with IS200TSVOH1 servo control card, easy replacement of spare parts

Product Specifications
1. Model: IS200TSVCH1ADC S1CX01H
2. System: GE Speedtronic Mark VI/Mark VIe
3. Function: Servo valve command output, LVDT position acquisition, signal conditioning
4. Power supply: 24VDC
5. Signal types: servo analog output, LVDT excitation and feedback, digital relay
Application Areas
1. Gas turbine fuel control valve servo control
2. Closed loop control of the main steam valve and regulating valve position of the steam turbine
3. Maintenance of Mark VIe control cabinet for power plant turbine unit
4. Replacement of spare parts for turbine control system in oil and gas power plants
5. Renovation and upgrade of control system for old power plant units
The IS200TSVCH1ADC S1CX01H servo terminal board is a core spare part for the speed control system of the power plant steam turbine unit servo valve control circuit maintenance.
