Hirschmann MM3-2FXM2 2TX1 Media Module

Hirschmann MM3-2FXM2/2TX1 is a Hirschmann MICE series industrial switch media module used for MS20/MS30/MS4128 modular switch expansion ports and industrial control network maintenance spare parts.

1. Two 100BASE-FX multi-mode SC fiber optic ports for long-distance transmission and strong resistance to electromagnetic interference
2. 2-channel 10/100BASE-TX RJ45 electrical ports, supporting automatic negotiation and automatic crossover
3. Panel link indicator light, quickly determine port communication status
4. Backboard power supply, low power consumption, easy module hot plugging and replacement
5. IP20 protection, wide temperature design, suitable for power plant and chemical control cabinet environments
6. Maximum transmission distance of optical fiber: 50/125 μ m, optical fiber can reach 5000 meters
7. RJ45 twisted pair cable with a maximum length of 100 meters
8. The power consumption of a single module is about 3.8W
9. Compatible with MICE series rack mounted modular switch backplane
10. Support switch redundant ring network protocol
11. Expansion of Fiber Optic Network for DCS Control System
12. Ethernet communication for factory automation equipment
13. Remote point signal transmission in industrial sites
14. Replacement and repair of the original Husman MICE medium module malfunction
15. Spare parts reserve for power plants and petrochemical industrial control rooms
This MM3-2FXM2/2TX1 optoelectronic hybrid medium module combines long-distance fiber optic and local electrical port access, and is a commonly used expansion spare part for MICE switch systems
