HIMA K9202 996920202 Cabinet Fan Module

HIMA K9202 996920202 is a dual fan cooling module for HIMax safety system cabinets, which provides heat dissipation for SIS safety control cabinets and outputs fan fault alarm signals.
Characteristics
1. Dual fan integrated structure, supports temperature control and speed regulation, automatically adjusts the speed according to changes in cabinet temperature
2. Fan fault detection, single fan failure can output hardware alarm to the safety system
3. Metal shell, suitable for explosion-proof conditions, meets the requirements for SIL safety system cabinet use
4. Embedded installation on the top of the cabinet, easy disassembly and maintenance
5. Equipped with a status indicator light, it can quickly determine if the fan is working abnormally on site

parameter
1. Module 24VDC power supply, dual fan configuration
2. Total air volume of 200m ³/h, noise level of approximately 50dBA
3. Working temperature -20~+70 ℃, protection level IP20
4. Fault contact output, docking system alarm circuit
5. Compatible with HIMA T4 series safety control cabinet
Application
1. HIMax SIS Safety Instrumented System Cabinet Cooling Unit
2. Chemical and petrochemical ESD emergency shutdown system cabinet spare parts replacement
3. Hardware maintenance of BMS control system for combustion management
4. Ventilation and heat dissipation of safety control cabinet in hazardous areas
5. Hardware upgrade accessories for the old HIMA safety system

When the temperature inside the cabinet is too high and the fan fault alarm is triggered, HIMA K9202 996920202 is the priority to inspect the heat dissipation components.
