500TRM02 1MRB150011R0001 Control Card

500TRM02 1MRB150011R0001 is a REB500 busbar protection system transformer signal conditioning card that collects CT/PT current and voltage signals.
Product Features

1. High voltage analog signal isolation conversion, converting the strong signal on the primary side into a weak signal that can be used on the board
2. Multi channel synchronous sampling ensures the accuracy of differential protection calculation
3. High voltage electrical isolation, resistant to strong electromagnetic interference from substations
4. Channel fault self check, abnormal upload alarm
5. Rack slot installation, compatible with 500CPU03 and 500MBA01
Product Specifications
1. Model: 500TRM02 1MRB150011R0001
2. Type: Signal conditioning transformer board
3. Adaptation: ABB REB500 busbar protection device
4. Input: CT, PT AC signals
5. Power supply: 24VDC
Application Areas
1. High voltage substation busbar protection cabinet
2. Replacement of maintenance spare parts for relay protection equipment
3. Renovation of power protection system
The 500TRM02 is a signal acquisition and maintenance spare part for REB500 for substation busbar protection.
