500MBA02 1MRB150003R000B control module

500MBA02 1MRB150003R000B is an AC160 DCS system analog output control module that converts controller digital signals into 4-20mA, 0-10V analog signals to drive regulating valves and actuators. It is a spare part for old rack boards.
Characteristics
1. Multiple analog output channels, stable output accuracy, suitable for process circuit adjustment.
2. Channel self diagnostic function can detect wire breakage and short circuit faults, and the board indicator light can quickly locate abnormal channels.
3. Backplane bus electrical isolation to resist electromagnetic interference inside the cabinet and reduce signal drift.
4. Standard rack card insertion structure, easy to disassemble and maintain on site.
5. Support output fault safety settings, which can maintain or reset the output in case of a fault.

parameter
1. Backplane bus interaction, module powered by 24VDC.
2. Output signal 4-20mA/0-10V configurable.
3. The overall power consumption of the machine is 6W, and there is isolation between channels.
4. Working temperature 0-60 ℃, protection level IP20.
5. Compatible with ABB AC160 system backplane rack.
Application
1. Analog output control of chemical power DCS system.
2. Valve and actuator give signal output.
3. The temperature and pressure regulation circuit signal is issued.
4. Replacement and maintenance of spare parts for ABB AC160 system.
5. Hardware renovation and maintenance of the old process control system.

When the analog output reading is abnormal or the valve signal is lost, 500MBA02 1MRB150003R000B is the module component that needs to be checked first.
