500CSP04 HE4013140002 1MRB150051R2 Controller Module

500CSP04 HE4013140002 1MRB150051R2 is the communication processor module of REB500 busbar protection system, responsible for data management and external communication of the entire protection device.
Product Features
1. Coordinate the protection of event records, fault recording data storage, and interface with backend monitoring systems
2. Multi protocol communication interface to complete protection information transmission and remote command reception
3. Real time self check communication link, network interruption will trigger local alarm
4. Reinforced board design to withstand complex electromagnetic environments in substations
5. Rack card structure, operating in conjunction with various REB500 acquisition cards
Product Specifications
1. Model: 500CSP04 HE4013140002 1MRB150051R2
2. Type: Communication Processor Module
3. Adaptation: ABB REB500 busbar protection system
4. Power supply: Backboard 24VDC
5. Function: Fault data storage, external communication interaction
Application Areas
1. High voltage substation busbar protection cabinet
2. Replacement of spare parts for relay protection devices
3. Substation protection system upgrade project
The data exchange operation and maintenance of the busbar protection device, this 500CSP04, is the core spare part for REB500’s external communication.
