086329-004 End Column Sensor Module

The ABB 086329-004 end column sensor board is a position signal acquisition component in old automation equipment, and is often used for equipment maintenance.
5 product features:
1. Real time collection of end column limit position signals and feedback to the main control system
2. Onboard signal conditioning, resistant to on-site electromagnetic interference, stable signal output
3. Standard rack plug-in card, plug and replace, convenient on-site maintenance
4. Equipped with fault recognition, abnormal states can be reported to the upper level for alarm
5. The board has high integration and does not require additional external signal conversion accessories

5 product parameters:
1. Adapt to ABB’s corresponding industrial control rack backplane
2. Digital sensing signal input and output
3. 24VDC industrial power supply
4. Industrial grade board, available in a wide temperature cabinet environment
5. Dedicated backplane interface, connected to the system bus
5 application areas:
1. End position detection of industrial equipment end columns
2. Limit signal acquisition of linear motion mechanism
3. Old ABB automation system signal processing
4. Feedback on the position of the assembly line actuator
5. Replacement and maintenance of imported equipment spare parts
Many old complete sets of equipment rely on ABB 086329-004 to complete signal acquisition for position limit detection.
